L Horizontal Lifting Clamp

L Horizontal Lifting Clamp(X)

L Horizontal Lifting Clamp

L Horizontal Lifting Clamp

BASIC INTRODUCTION

Product Name: TOYO L Horizontal Lifting Clamp
Working Load Limit (WLL): The working load limit refers to the maximum load that the clamp is authorized to support when used in pairs with a lift angle of 60°. (The specific value is not mentioned.) During lifting operations, the clamps can be used in pairs or in multiples.

FEATURES

To avoid possible personal injury or damage to the equipment, snatch or shock loading should be avoided.

See our Rigging and Sling Catalog for more info!

Product Details

Specs

Model		L0.8	L1	L1.6	L2.5	L2.5(B)	L3.2	13.2(B)	L5	L5(B)	L10
Load Capacity	TON	0.8	1	1.6	2.5	2.5	32	3.2	5	5	10
Jaw Opening	MM	0-15	0-20	0-25	0-30	25-50	0-40	30-60	0-50	50-80	20-100
Weight	KG	2	4	6.5	11	11	12 5	12.5	19	20	43

Application

It is suitable for relevant working scenarios that require horizontal lifting.
