T-PORTABLE ELECTRIC HOIST

BASIC INTRODUCTION

Control: Direct – coupled DC control, quick – connect aviation plugs for switches and cords.
Motor: Industrial brushless motor, 110V/220V options, 220°C – resistant enameled wire.
Brake: Dual system with mechanical ratchet & electrical stop, durable oil – immersed copper pads.
Safety: Automatic stops for overwound or reversed steel cable.

FEATURES

Simple wiring, easy maintenance, low failure rate.
Strong power, flexible voltage, heavy – duty capable.
Instant braking, long – lasting brake pads.
Dual – limit protection for safety.

See our Winch Catalog for more info!

Product Details

Specs

Model	Load Capacity (kg)	Phase Voltage Frequency	Motor Power (kW)	Wire Rope Diameter x Length (mm x m)	Lifting Speed (m/min)	Wire Rope Length (m)	Dimensions: Length x Width x Height (mm)	Quantity /Ctn (pcs)	Net Weight/ Gross Weight (kg)
T-160	160 kg	1P,220V,50HZ	1.2	5X30	19	30	240x180x660	1	15/16
T-180	180 kg	1P,220V,50HZ	1.2	5X30	19	30	240x180x660	1	15/16
T-230	230 kg	1P.220V,50HZ	1.3	5X30	19	30	240x180x660	1	16/17
T-250	250 kg	1P,220V,50HZ	1.3	5X30	19	30	240x210x670	1	20/21
T-300	300 kg	1P,220V,50HZ	1.3	5X30	19	30	240x210x670	1	20/21
T-280	280 kg	1P,220V,50HZ	1.3	5X30	19	30	240x210x670	1	20/21
T-360	360 kg	1P.220V,50HZ	1.3	5X30	19	30	240x210x670	1	23/24
T-500	500 kg	1P220V,50HZ	1.8	5X30	19	30	240x210x670	1	23/24

Application

Manufacturing for equipment handling
Warehousing and logistics for cargo operations
Construction for material lifting
Equipment maintenance for machinery hoisting
